Flow Switch

Get a Price/Quote

MOQ : 10 Pieces

Flow Switch Specification

Control Type
Mechanical switch

Features
Corrosion-resistant, easy installation, adjustable sensitivity

Shape
Compact rectangular body with paddle

Technology
Electromechanical paddle type

Coating Type
Nickel-plated brass

Installation Type
Inline pipe mounting

Mounting Type
Horizontal or vertical mounting

Voltage
250V AC

Connectivity Type
SPDT micro switch

Operating Pressure
1-10 bar

Coverage Area
Depends on pipe installation

Working Temperature
-10C to +80C

Application
Industrial and commercial water flow detection

Max Flow Rate
Up to 10 m3/h

Diameter
1 inch (typical), options available

Pressure
Max 16 bar

Minimum Flow Rate
1.5 L/min

Body Material
Brass

Cable Gland
PG9

Paddle Material
Stainless Steel

Switch Contact Rating
5A at 250V AC

Adjustment
Paddle length adjustable for pipe size

Response Time
< 2 seconds

Ingress Protection
IP65

Flow Switch Trade Information

Minimum Order Quantity
10 Pieces

Payment Terms
Cash in Advance (CID)

Supply Ability
1000 Pieces Per Month

Delivery Time
5-7 Days

Main Domestic Market
All India

About Flow Switch

Purchase this dominant Flow Switch designed for first-class performance in water flow detection across industrial and commercial installations. With a switch contact rating of 5A at 250V AC and a swift response time of under 2 seconds, this robust device capitalises on its stainless steel paddle and noble, nickel-plated brass body for superior corrosion resistance. The adjustable paddle suits various pipe sizes, supporting flows from 1.5 L/min up to a maximum of 10 m3/h. Popular for inline mounting with SPDT connectivity, its IP65 ingress protection and versatile design make it the leading choice among Indian suppliers, traders, and service providers.

Versatile Applications and Distinct Advantages

This Flow Switch is commonly used for monitoring water flow in both industrial and commercial environments. Its primary advantage lies in reliable detection and quick response, ensuring machinery safety and efficient process control. The adjustable paddle accommodates different pipe diameters, adding to its versatility. Beyond typical water flow sensing, it can serve in HVAC systems, fire protection lines, and other fluid monitoring scenarios, making it a popular and valuable component in various engineering applications.

Timely Delivery and Flexible Payment Terms for the Indian Market

Estimate a prompt delivery time, with logistics tailored to major domestic markets across India. Flow Switch orders are processed efficiently, ensuring customers receive their products within standard timeframes and at competitive charge rates. Multiple payment terms are available, accommodating both advance and post-invoice transactions for a seamless procurement process. These logistics and payment solutions guarantee a smooth buying experience for suppliers, traders, and service providers nationwide.

FAQ's of Flow Switch:

Q: How does the Flow Switch operate, and what technology does it use?

A: The Flow Switch utilizes an electromechanical paddle type mechanism. When fluid passes through the pipe, it moves the paddle. This triggers the mechanical SPDT micro switch inside, indicating the presence or absence of flow, and allowing for direct control of circuits and alarms.

Q: What are the advantages of choosing a stainless steel paddle and nickel-plated brass body?

A: The stainless steel paddle ensures durability and corrosion resistance, making it ideal for aggressive environments. The nickel-plated brass body provides added strength and robustness, ensuring long-lasting and reliable operation in various water flow applications.

Q: When should paddle length adjustment be performed?

A: Adjust the paddle length during installation to match the specific pipe diameter and desired sensitivity. Proper adjustment optimises the detection range and accuracy of the switch for different flows and pipe sizes.

Q: Where is this Flow Switch best installed for optimal performance?

A: This flow switch is best installed either horizontally or vertically in an inline pipe configuration. Ensure it is placed in a section with stable flow to capitalise on accurate sensing, and avoid areas prone to turbulence or air pockets.

Q: What is the process for connecting the Flow Switch electrically?

A: Connect the flow switch to your control system using the SPDT micro switch terminals via the PG9 cable gland. Ensure all wiring is done according to safety standards and use the 250V AC supply, respecting the 5A rating for safe operation.

Q: What benefits can users expect from opting for this Flow Switch in commercial installations?

A: Users benefit from reliable flow detection, minimal maintenance due to corrosion-resistant materials, and easy integration into existing water monitoring or safety systems. The fast response time and wide operating pressure range enhance its suitability for diverse commercial water management needs.
