1620 Lpm Capacity Electrical Driven Main Pump

Get a Price/Quote

MOQ : 10 Pieces

1620 Lpm Capacity Electrical Driven Main Pump Specification

Coverage Area
Large Industrial/Commercial Buildings

Operating Pressure
7-10 Bar

Voltage
415V, 3 Phase, 50Hz

Features
Corrosion Resistant, Continuous Duty, Easy Maintenance

Mounting Type
Base Plate Mounted

Working Temperature
0C to 50C

Installation Type
Horizontal/Skid Mounted

Technology
Centrifugal Pump

Fire Extinguisher Type
Main Pump for Wet Hydrant System

Coating Type
Anti-corrosion Painted

Control Type
Electric Automatic Control Panel

Energy Efficiency Rating
High Efficiency

Fire Class
Class A & B

Shape
Horizontal Cylindrical

Connectivity Type
Wired Electric

Application
Fire Fighting, Industrial Water Supply

Max Flow Rate
1620 Lpm (Liters per minute)

Diameter
100 mm

Capacity
1620 Lpm

Pressure
7-10 Bar

Pump Speed
2900 RPM

Material
Cast Iron/SS Impeller

Inlet/Outlet Size
100 mm / 80 mm

Protection
IP55 Motor Protection

Motor Power
25 HP Electric Motor

Noise Level
Low Noise Operation (<70 dB)

Seal Type
Mechanical Seal

Suction Type
End Suction Pump

Net Weight
Approx. 250 kg

1620 Lpm Capacity Electrical Driven Main Pump Trade Information

Minimum Order Quantity
10 Pieces

Payment Terms
Cash in Advance (CID)

Supply Ability
1000 Pieces Per Month

Delivery Time
5-7 Days

Main Domestic Market
All India

About 1620 Lpm Capacity Electrical Driven Main Pump

Access the illustrious 1620 Lpm Electrical Driven Main Pump, designed for commanding performance in challenging scenarios. Get masterful delivery with its potent 25 HP electric motor, driving a durable cast iron or stainless-steel impeller at 2900 RPM. Pick yours for superior fire-fighting and industrial water supply, featuring a robust end suction mechanism, mechanical seal, and low-noise operation (<70 dB). This corrosion-resistant centrifugal pump boasts IP55 motor protection, anti-corrosion coating, and easy maintenance. With high energy efficiency for continuous duty and coverage for large industrial or commercial sites, it stands as a trusted choice for rigorous applications.

Exceptional Features for Diverse Industrial Surfaces

This main pump offers extra features such as anti-corrosion painted coating and continuous duty operation, making it ideal for fire fighting and industrial water supply. The horizontal/skid mounting allows for stable placement on various surfaces, from concrete platforms to industrial flooring. Its robust construction ensures specific use in wet hydrant systems, while its general use spans a broad range of safety and process water supply applications for large buildings and facilities.

Order Processing, Shipment & Payment Terms

We prioritize efficient order processing and rapid shipment. Payment terms are flexible, tailored to your procurement needs, with industry-standard options offered. Shipment is managed through leading logistics partners, originating from major FOB ports in India. After order placement, allow a short charge processing window-delivery time estimates are provided based on location and stock. Each shipment is handled with care to guarantee fast, secure delivery of your selected pump.

FAQ's of 1620 Lpm Capacity Electrical Driven Main Pump:

Q: How does the 1620 Lpm Main Pump perform in fire-fighting applications?

A: The pump delivers a potent 1620 liters per minute flow rate, making it masterful in both Class A and B fire scenarios. Its reliable pressure output and compatibility with wet hydrant systems ensure effective fire suppression in large industrial and commercial buildings.

Q: What materials are used in the construction of this pump?

A: This main pump is built with a corrosion-resistant cast iron or stainless-steel impeller, protected by anti-corrosion paint. Its robust construction ensures long life and resilience in demanding environments.

Q: Where can this pump be installed?

A: It can be horizontally or skid-mounted on industrial or commercial flooring, suitable for installation in large spaces such as factories, warehouses, and multi-story office buildings requiring dependable water supply solutions.

Q: What is the process for ordering and receiving the pump?

A: Simply contact our sales team to place your order. Once processed, your pump will be shipped from a major Indian FOB port, with tracking and delivery updates provided. Standard delivery times depend on location and may vary based on order volume.

Q: How does the pump ensure energy efficiency and low maintenance?

A: This model features a high-efficiency motor and is built for continuous duty. The mechanical seal design, anti-corrosion coating, and high-quality materials contribute to its easy maintenance and long-lasting performance.
