32 Zone Fire Alarm Panel

Get a Price/Quote

MOQ : 10 Units

32 Zone Fire Alarm Panel Specification

Sensor Type
Compatible with smoke, heat, and manual call point sensors

Working Current
400 mA (alarm condition, approximate)

Sensitivity
Adjustable (per zone)

Wireless
No (wired system)

Control Distance
Up to 1 km (with suitable cabling)

Voltage
24V DC internal, 230V AC input

Alarm Density
Programmable per zone

Standby Current
150 mA (approximate)

Sensor Life
Typically 5-10 years (sensor dependent)

Alarm time
Continuous until reset

Sensor Cable
2-core, 1.5 sq mm (recommended)

Noise Level
85 dB or more (internal buzzer)

Suitable For
Large buildings, offices, factories, commercial complexes

Alarm startup time
Within 3 seconds

Power Supply
AC 230V 10%, 50Hz; Battery Backup 24V DC

Alarm Light Color
Red

Remote Control
Supported via key switch or remote module

Detection Range
Up to 100 meters (depends on detector type)

Test Facility
Manual and auto test modes

Number of Zones
32 zones

Zone Capacity
Up to 20 detectors or call points per zone

System Reset
Manual (via front panel)

Battery Type
2 x 12V Sealed Lead Acid (24V DC backup)

Weight
Approx. 10 kg (without batteries)

Event Memory
Stores up to 100 events

Operating Temperature
0C to 50C

Display
LED indicators for Fire, Fault, Zone status; LCD (optional)

Humidity Tolerance
Up to 95% RH (Non-condensing)

Dimensions
Approx. 500 mm x 400 mm x 120 mm

Programming
Front panel keypad or DIP switch

Enclosure
Powder coated MS, wall mounted

Output Relays
Fire and Fault relays, auxiliary outputs; 2A @ 28V DC

32 Zone Fire Alarm Panel Trade Information

Minimum Order Quantity
10 Units

Payment Terms
Cash in Advance (CID)

Supply Ability
1000 Units Per Month

Delivery Time
5-7 Days

Main Domestic Market
All India

About 32 Zone Fire Alarm Panel

Experience instant savings with our top-tier 32 Zone Fire Alarm Panel, acclaimed for its unmatchable accuracy and pristine performance. Engineered for large buildings, offices, and factories, this system supports up to 20 detectors per zone, featuring LED indicators, advanced relays, and a durable, powder-coated enclosure. With uncommon reliability, event memory for 100 incidents, and both manual and auto test modes, it offers superior safety. Its robust design, easy programming, and remote-control compatibility make it the top choice for commercial fire protection needs across India.

Competitive Advantages: Trusted by Professionals Nationwide

The 32 Zone Fire Alarm Panel delivers advanced fire safety with unmatchable reliability, ideal for large commercial complexes, factories, and office spaces. Widely acclaimed by service providers, suppliers, and facility managers across India, this panel is suitable for any general or specialized fire protection requirement. Its exceptional detection accuracy, flexibility to accommodate multiple sensor types, and robust build offer pristine safety assurance, making it the preferred solution in diverse environments where secure, scalable fire management is crucial.

Sample Policy and Packaging: Secure Supply and Timely Dispatch

Our supply process for the 32 Zone Fire Alarm Panel is prompt and reliable. Upon proposal amount confirmation, units are carefully packaged in sturdy, secure materials to ensure pristine condition on arrival. Sample panels can be shipped on request to eligible trade partners for evaluation purposes. Typical delivery time ranges from 7 to 14 business days after order processing, ensuring swift fulfillment for urgent safety projects throughout India. Feel free to contact us for sample and bulk order proposals.

FAQ's of 32 Zone Fire Alarm Panel:

Q: How is the 32 Zone Fire Alarm Panel programmed for individual zones?

A: Programming the panel can be easily accomplished via the front panel keypad or by adjusting DIP switches, allowing you to configure each of the 32 zones according to unique safety requirements.

Q: What is the recommended usage environment for this fire alarm system?

A: The panel is best suited for large-scale facilities such as offices, factories, commercial complexes, and institutional buildings, providing unmatchable fire detection across multiple zones.

Q: What are the benefits of using an acclaimed 32 zone system over smaller panels?

A: With support for up to 20 detectors or call points per zone and extensive control distance, the panel ensures comprehensive coverage and advanced monitoring, reducing fire response times and increasing safety.

Q: When can customers expect their ordered panels to be shipped?

A: Orders are typically processed and shipped within 7 to 14 business days after receipt of the proposal amount, with sample units available for trade evaluation as per our supply policy.

Q: Where can the 32 Zone Fire Alarm Panel be installed?

A: The system is wall-mounted and designed for indoor installation in any commercial or large residential building, with rugged enclosures offering pristine durability in varied Indian climates.

Q: What is the process to reset the fire alarm system in case of an emergency?

A: System reset is performed manually via the front panel, allowing quick restoration after addressing a fire or fault status to ensure continuous and reliable protection.
