4 Loop Card Fire Alarm Panel

Get a Price/Quote

MOQ : 10 Units

4 Loop Card Fire Alarm Panel Specification

Noise Level
< 75 dB during alarm at panel

Sensitivity
Configurable per EN54 standard

Alarm startup time
3 seconds

Alarm time
Continuous until reset

Sensor Cable
Twisted pair, 1.5 mm2 recommended

Sensor Type
Smoke, heat, and multi-sensor compatible

Wireless Distance
N/A (wired system)

Alarm Density
0.6-1.5% obs/m (for smoke detection)

Standby Current
250mA

Wireless
No (wired loop type)

Suitable For
Industrial buildings, commercial complexes, hospitals, large offices

Working Current
500mA

Voltage
24V DC (internal circuits)

Sensor Life
Up to 5 years (typical for detector)

Control Distance
Up to 1 km with repeater support

Power Supply
230V AC 50Hz, with battery backup

Alarm Light Color
Red

Remote Control
Supported via dedicated panel or network

Detection Range
Up to 100 meters (depends on detector type)

Battery Backup
12V, 7AH x 2 SMF batteries

Communication Interface
RS-485, Ethernet (Modbus/RTU, TCP/IP)

Output Relays
Fire, Fault, and programmable relays

Number of Loops Supported
4 loops (expandable up to 512 devices per loop)

System Programming
Via onboard keypad and external PC software

Zone Indication
Programmable, up to 64 zones

Display
LCD graphical display with backlight

Panel Type
Microprocessor-based addressable panel

Event Log
Up to 1000 events, non-volatile memory

4 Loop Card Fire Alarm Panel Trade Information

Minimum Order Quantity
10 Units

Payment Terms
Cash in Advance (CID)

Supply Ability
1000 Units Per Month

Delivery Time
5-7 Days

Main Domestic Market
All India

About 4 Loop Card Fire Alarm Panel

Redeem peace of mind with the latest 4 Loop Card Fire Alarm Panel, engineered for demanding industrial and commercial settings in India. This microprocessor-based, addressable marvel supports up to 4 loops, each expandable for an enviable 512 devices per loop. Boasting a polished LCD graphical display and competitive pricing, it ensures swift detection, programmable zone indication, and robust event logging (1,000 events stored). With fire, fault, and programmable relays, plus advanced communication interfaces (RS-485, Ethernet), this solution is a superb blend of sophistication, reliability, and value, perfect for mission-critical environments.

Versatile Applications and Advantages of the 4 Loop Card Fire Alarm Panel

This fire alarm panel is ideal for industrial buildings, commercial complexes, hospitals, and large offices. Its key advantage lies in the scalability of up to 512 devices per loop and programmable zone indication across 64 zones. Designed for surface mounting, it offers enviable integration with modern infrastructure, ensuring widespread coverage and responsive detection for every type of commercial surface. Leveraging advanced microprocessor technology, its sophisticated features provide robust fire protection and operational flexibility.

Certifications, Domestic Reach, and Swift Delivery

Our 4 Loop Card Fire Alarm Panel adheres to EN54 sensitivity standards, guaranteeing a polished and secure solution. We primarily serve the Indian domestic market, catering to service providers, suppliers, and traders nationwide. Each shipment is securely packaged, ensuring safe transit and prompt delivery. We pride ourselves on offering the lowest price while maintaining a marvelous standard of quality. Expect shipment and delivery within the stipulated time, providing reliable protection sooner.

FAQ's of 4 Loop Card Fire Alarm Panel:

Q: How does the programming process work for the 4 Loop Card Fire Alarm Panel?

A: Programming is user-friendly and can be accomplished via the onboard keypad or external PC software, allowing easy customization for detection sensitivity, zone assignment, and relay outputs.

Q: What areas are suitable for installing this fire alarm panel?

A: This panel is designed for installation in industrial buildings, commercial complexes, hospitals, and large offices, where comprehensive and expandable fire detection is paramount.

Q: When can I expect delivery of the 4 Loop Card Fire Alarm Panel after placing an order?

A: We ensure that shipment and delivery are prompt, with secure packaging to guarantee the product reaches you within the promised timeframe.

Q: Where does this product comply in terms of fire detection standards?

A: The panel and its compatible detectors offer configurable sensitivity according to EN54 standards, meeting stringent safety requirements.

Q: What are the benefits of choosing a microprocessor-based, addressable panel?

A: This advanced panel type provides precise device monitoring, rapid event log storage, programmable zones, and remote control capabilities for impeccable safety management.
